COPPER PLATE: When it comes to C11000/ C12200 Copper Plate BAUDUCCO FOODS INC is a name that comes to mind. We have a team of highly qualified, motivated & experienced staff in production and sales to meet customers ever growing quality and service expectation. We offer the best quality C11000/ C12200 Copper Plate which are used widely and are demanded all over the world. We are among the reckoned names in the industry, engaged in Manufacturing, Exporting lying wide assortment of C11000/ C12200 Copper Plate in the market. These are available in different grades and dimensions and can be customized as per the clients’ specification and requirement. |
|
Cu-DHP Cll 000 Copper Plate / ETP Cll OOP Copper Sheet
|
|
|
Grade
|
C10100,C10200zC10300zC10400zC10500zC10700/C10800zC10910,C10920,C10930,C11000,C11300,C11400,C11500,C11600,
C12000/C12200/C12300zC12500zC14200/C14420zC14500zC14510/C14520zC14530/C17200zC19200,
C21000zC23000,C26000zC27000zC27400,C28000zC33000zC33200/C37000zC44300zC44400zC44500/C60800,
C63020,C65500,C68700,C70400,C70620zC71000,C71500zC71520zC71640zC72200
TlzT2zT3,TUlzTU0zTU2zTPlzTP2zTAg0.1z |
|
Shape
|
Flat plate . Flat bar , Strip, Coil
|
|
Standard
|
DIN GB ISO JIS BA ANSI
|
|
Thickness
|
0.3mm~100mm
|
|
Width
|
50mm~2500mm
|
|
Length
|
1000mm~12000mm
|
|
Surface
|
Mill finish, polished, anodizing, brushing, sand blasting, powder coating,etc
|
|
Applications
|
1) Further making utensil. 2) Solar reflective film. 3) The appearance of the building. 4) lnterior decorating:ceilings;walls:etc.
5) Furniture cabinets. 6) Elevator decoraction. 7) Signs,nameplate,bags making.8) Decorated inside and outside the car. 9) Household appliances:refrigerators,microwave ovens,audio equipment.etc.
10) The consumer electronics:mobile phones:digital cameras; MP3,Udisk,etc.
|
|
Packing
|
Standard export seaworthy package or as required
|
|
GB
|
ISO
|
ASTM
|
JIS
|
|
TU1
|
Cu-OF
|
C10200
|
C1020
|
|
T2
|
Cu-RTP
|
C11000
|
C1100
|
|
TP1
|
Cu-DLP
|
C12000
|
C1201
|
|
TP2
|
Cu-DHP
|
C12200
|
C1220
|
|
GB
|
Composition(%)
|
||||
|
Cu
|
P
|
O
|
Other
|
||
|
TU1
|
99.97
|
0.002
|
less than 0.002
|
balance
|
|
|
T2
|
99.9
|
－
|
-
|
balance
|
|
|
TP1
|
99.9
|
0.004-0.012
|
-
|
balance
|
|
|
TP2
|
99.9
|
0.015-0.040
|
-
|
balance
|
|
|
ASTM
|
Composition(%)
|
||||
|
Cu
|
P
|
O
|
Other
|
||
|
C10200
|
99.95
|
0.001-0.005
|
-
|
balance
|
|
|
C11000
|
99.9
|
－
|
-
|
balance
|
|
|
C12000
|
99.9
|
0.004-0.012
|
-
|
balance
|
|
|
C12200
|
99.9
|
0.015-0.040
|
-
|
balance
|
|
| High purity, low oxygen content, excellent electrical conductivity, suitable for fine beating, good thermal and electric path, processing, ductility, corrosion resistance and weather ability. |
